Gas-Thread Cable Glands On American Electrical, Inc.

Catalog

1 - 20 of 20 | Results Per Page | View | Unit of Measure

1

Request Information

Clear Filter

Nominal Thread Size Per Gas Pipe Thread (in)

Thread Length (mm)

Wrench Width (mm)

Cable Diameter (in)

Suitable for Cable Diameter (mm)

Item #	Nominal Thread Size Per Gas Pipe Thread	Thread Length	Wrench Width	Cable Diameter	Suitable for Cable Diameter	Add To Cart/Request Quote

1000.1/2G	N/A 1 in	N/A 8 mm	N/A 24 mm	N/A 1/2 in	N/A 8.0 to 15.0 mm	Request Quote
1000.11/2G	N/A 1 in	N/A 12 mm	N/A 55 mm	N/A 1-1/2 in	N/A 25.0 to 35.0 mm	Request Quote
1000.1G	N/A 1 in	N/A 11 mm	N/A 36 mm	N/A 1 in	N/A 17.0 to 25.5 mm	Request Quote
1000.21/2G.500	N/A 2 in	N/A 18 mm	N/A 80 mm	N/A 2-1/2 in	N/A 45.0 to 50.0 mm	Request Quote
1000.21/2G.560	N/A 2 in	N/A 18 mm	N/A 80 mm	N/A 2-1/2 in	N/A 50.0 to 56.0 mm	Request Quote
1000.2G	N/A 2 in	N/A 12 mm	N/A 65 mm	N/A 2 in	N/A 37.0 to 49.0 mm	Request Quote
1000.3/4G	N/A 3/4 in	N/A 10 mm	N/A 30 mm	N/A 3/4 in	N/A 12.5 to 20.5 mm	Request Quote
1000.3/8G	N/A 3 in	N/A 6 mm	N/A 21 mm	N/A 3/8 in	N/A 5.5 to 12.0 mm	Request Quote
1000.3G.630	N/A 3 in	N/A 18 mm	N/A 80 mm	N/A 3 in	N/A 58.0 to 63.0 mm	Request Quote
1000.3G.700	N/A 3 in	N/A 18 mm	N/A 95 mm	N/A 3 in	N/A 63.0 to 70.0 mm	Request Quote
181/2G.11.26	N/A 1 in	N/A 12 mm	N/A 24 mm	N/A 1/2 in	N/A 9.0 to 11.0 mm	Request Quote
181/2G.16.26	N/A 1 in	N/A 14 mm	N/A 26 mm	N/A 1/2 in	N/A 11.0 to 13.0 mm	Request Quote
1811/2G.36.26	N/A 1 in	N/A 17 mm	N/A 55 mm	N/A 1-1/2 in	N/A 28.0 to 32.0 mm	Request Quote
1811/4G.29.27	N/A 1 in	N/A 17 mm	N/A 45 mm	N/A 1-1/4 in	N/A 24.0 to 28.0 mm	Request Quote
181G.29.26	N/A 1 in	N/A 17 mm	N/A 45 mm	N/A 1 in	N/A 20.0 to 24.0 mm	Request Quote
183/4G.21.26	N/A 3/4 in	N/A 16 mm	N/A 32 mm	N/A 3/4 in	N/A 13.0 to 16.5 mm	Request Quote
183/4G.21.27	N/A 3/4 in	N/A 16 mm	N/A 36 mm	N/A 3/4 in	N/A 16.5 to 20.0 mm	Request Quote
183/8G.09.26	N/A 3 in	N/A 12 mm	N/A 20 mm	N/A 3/8 in	N/A 7.0 to 9.0 mm	Request Quote
1848.26	N/A 2 in	N/A 20 mm	N/A 64 mm	N/A 2 in	N/A 36.0 to 40.0 mm	Request Quote
1848.27	N/A 2 in	N/A 20 mm	N/A 64 mm	N/A 2 in	N/A 40.0 to 44.0 mm	Request Quote
